Ссылка №	Артикул	Кол-во	Наименование	Включая	Цена
0010	10D132-0110-F8		* ENGINE, 163CC Briggs & Stratton Snow Series (Engine Model: 10D132-0110-F8)
0010-10	591619		GUARD, Muffler (Use on 163CC Engine)
0010-20	590638		SCREW, Muffler Guard (Use on 163CC Engine)
0010-30	794641		CAP, Fuel Tank (Use on 163CC Engine)
0050	703296		BOLT, Carriage, 5/16-18 x 1-1/2, G5
0060	028X76MA		NUT, Push, 1/4
0070	690272MA		NUT, Flange, 5/16-18
0090	1501109MA		PULLEY, Engine
0100	703298		WASHER, Flat, 5/16
0110	703299		CAPSCREW, Hex Head, 5/16-24 x 1-1/4, G5
0120	1733324SM		V-BELT, 3L 33.03
0130	1751417YP		BELT, Auger
0140	1739070YP		BELT GUIDE
0150	71060MA		LOCKWASHER, Spring, 5/16
0170	1687797YP		BRACKET, Idler
0180	1501065MA		BUSHING, Ider Bracket
0190	165X159MA		SPRING, Extension, Auger
0200	1502120MA		IDLER, Plastic Ball Bearing
0210	1960251SM		NUT, Center Lock, 3/8-16
0220	1960032SM		SCREW, Hex Head, 3/8-16 x 1-1/4
0230	1752397YP		AUGER IDLER
0240	1501200MA		SPACER, Plastic, 1/2 ID x 1 OD, 1-3/4
0250	703128		WASHER, 1/2
0270	403162MA		PIN, Hair
0290	1753969BMYP		COVER, Bottom
0300	703054		SCREW, Hex Washer Head, Taptite, 1/4-20 x 5/8
0320	1754891ZYP		FRAME BOX
0350	703228		SCREW, Thread Rolling, 5/16-18 x 3/4
0360	1753893YP		COVER, Belt
0370	1751355YP		SCREW, Hex Washer Head, Taptite, 1/4-20 x 3/4
0390	1733868ASM		PLATE, Seal
0390-10	1754847YP		SEAL, Shaft, 3/8" Thick (Use on 163CC Engine)
0400	1750172YP		STRIP, Seal
0410	910828MA		BOLT, Hex, 5/16-24 x 1
0500	703302		WASHER, Flat, 5/16
0520	165X164MA		SPRING, Extension, Idler
0530	7091890SM		WASHER, Internal Lock, 1/4
0540	1754362YP		SPACER BLOCK (Use on 163CC Engine)
