Ссылка №	Артикул	Кол-во	Наименование	Включая	Цена
10	703589		CAPSCREW, Hex Head, 3/8-16 x 2, G5
20	1732470SM		KNOB, Deflector
30	1736192YP		LEVER, Deflector
40	703591		WASHER, 3/8 x 1-1/2 OD
50	50786MA		SPRING, 3/4"
60	703590		WASHER, Flat, 3/8 x 13/16 OD
70	703117		NUT, Nylock, GR5, 3/8-16
80	1739782AYP		LEVER, Clutch, L.H.
100	703047		SPEED LEVER ASSEMBLY
120	703588		CAPSCREW, Hex Head, 1/4-20 x 1 3/4, GR5
130	1737684YP		BRACKET, Controls
140	1737331YP		ROD, Speed Select
150	703409		NUT, Hex, 5/16-18
170	703331		NUT, Hex Flange Serrated Lock, 5/16-18
180	1739510YP		BRACKET, Lower Mounting
190	1739290YP		BALL JOINT, Quick Release
220	1752164YP		HARNESS, On/Off, HHG
230	1755059YP		WIRING HARNESS
235	703463		NUT, Hex Flange, ESNA, 1/4-20
300	703232		NUT, Hex Lock ESNA Light 1/4-20
310	703466		SCREW, Hex Washer Head, Taptite, 1/4-20 x 3/4
330	1755373YP		PANEL ASSEMBLY
335	1754422YP		FILLER STRIP, Center Piece
360	1753529YP		BOLT, Shoulder, Hex Washer Head, 1/4 x 1-1/2
370	1960282SM		BOLT, Carriage, 5/16-18 x 3/4, G5
390	1739500BMYP		SUPPORT, Dash
395	1737510YP		CABLE, Steering Control
400	703221		CABLE & SPRING ASSEMBLY, Auger Drive, R.H.
410	1739783AYP		LEVER, Clutch, RH
420	703412		NUT, Nylock, 10 x 24
430	1752242YP		SWITCH, Heated Hand Grip
435	703044		SCREW, Square, 1/8-20 x 1/32
440	703223		SPACER, Stepped
445	703134		BOLT, 10-24 x 1.5, GR5
450	703045		CAPSCREW, Hex Head, 1/4-20 x 1-3/4, G5
460	1737552YP		BRACE
470	1737531AYP		HANDLE, Upper, R.H.
480	1737532AYP		HANDLE, Upper, L.H.
490	703168		CARRIAGE BOLT, 5/16-18 x 2.25
500	1737274AYP		HANDLE, Lower
510	703065		KNOB, Wing, 5/16-18
